11. When the window returns to two screens—PANEL CONTENT and PANEL OPTIONS—touch the radio button
beside the new view to activate it (this puts a dot inside the circle).
12. Touch Save.
13. Touch the STATUS menu icon to see the new appearance.
To choose an existing layout, navigate to the PANEL CONTENT screen and touch the radio button beside the layout, then
touch the STATUS menu icon.
Remove a Layout
To delete a layout:
Log in with Administrator or Service access.
Using the Edit Icon to Customize Layout
The Liebert® APM Plus Touchscreen Control Panel layout can also be changed with the Edit icons on the screen for a user
logged-in as Operator, Administrator, or Service. The Edit icon can be used to add or remove panels, resize panels, rearrange
panels, and change monitored parameters.
To use the Edit icon:
1. Touch the Edit icon on the panel to be edited and hold it until a Change content button appears on the
panel (about 1 second).
Change Panel
2. Touch an icon to choose the data to be displayed in the panel (see Figure 5.13 on the next page); choices are:
• One-Line
• Run Hours
• Status
• Event Log
• Alarms Battery
• Cycle Monitor Summary
Change UNIT STATUS Panel Content
3. To change the UNIT STATUS panel’s data:
a. Touch the Edit icon on the UNIT STATUS panel and hold it until the Change Content button and X’s
appear beside the parameters.
b. Touch the X beside the parameter to be removed from the panel. The Add Parameter icon (+) will appear
in the panel if another parameter can be added. The number of parameters possible is based on whether
the Status Gauge is displaying.
c. Touching the add Parameter icon brings up a window to add parameters not already shown on the
UNIT STATUS panel.
d. Touch a parameter’s icon to add it to the UNIT STATUS panel. Resize or remove a panel.
4. Touch and hold the Edit icon again while the Change content button is displayed.
5. Release the icon. Resize handles will appear around the panel and a large X will appear at the top right corner.
6. Pull on a handle to resize the panel, or
7. Touch the large X to delete the panel.
