Vertiv Liebert APM2 - Efficiency and Loss

Item Unit
Rated Power (kVA)
120
Lower Limit: -0.5, -1 , -2 , -3 , (-10%); Default: -10%
Slew rate (maximum change rate of
synchronization frequency)
Hz/s 0.6; setting range: 0.1 to 3
1
Factory set to 380 V - 400 V or 415 V can be selected by service engineer at site.
2
Factory set to 50 Hz - 60 Hz can be selected by service engineer at site. Note that the system frequency can be changed only when the UPS is on
bypass. It is strictly prohibited to change the system frequency when the UPS is on inverter.
3
EN 50091-3 (1.4.58) crest factor 3:1, non-linear load.
Table 12.6 Inverter Output (to Critical Load) (continued)
12.7 Electrical Characteristics (Bypass Input)
Item Unit
Rated Power (kVA)
120
Rated AC voltage
1
VAC
380/400/415, three-phase four-wire, sharing neutral with the rectifier input and providing neutral
reference to the output.
Rated current
380 V A 183
400 V A 173
415 V A 167
Frequency
2
Hz 50/60
Bypass voltage tolerance %VAC
Upper limit: +10, +15 or +20, Default: +15
Lower limit: -10, -20, -30 or -40, Default: -20
Bypass frequency tolerance % ±10
1
Factory set to 380 V - 400 V or 415 V can be selected by service engineer at site.
2
Factory set to 50 Hz - 60 Hz can be selected by service engineer at site.
3
The short time withstand current of the bypass thyristor is based on one of the manufacturers.
Table 12.7 Bypass Input
12.8 Efficiency and Loss
Item Unit
Rated Power (kVA)
120
ECO mode full load loss kW 1.2
Double conversion mode efficiency Up to 97%
ECO mode efficiency Up to 99%
Table 12.8 Electrical characteristics (Efficiency and Loss)
174 Proprietary and Confidential ©2023 Vertiv Group Corp. 12 Specifications
Vertiv™ Liebert® APM2 30 to 120 kVA Modular UPS User Manual
