12.3 Frame 1 Mechanical Characteristics
Item Unit
Rated Power (kVA)
Without Switch Single Switch Four Switches
120
Dimensions
(W × D × H)
Packing excluded mm 602.4/930.5/2002.7 602.4/930.5/2002.7 602.4/930.5/2002.7
Packing included mm 800/ 1100/2000 800/ 1100/2000 800/ 1100/2000
Net weight kg 500 500 500
Gross weight kg 520 520 520
Color Black ZP7021
Protection degree, IEC (60529) IP20 (front door open or closed)
Table 12.3 Mechanical Characteristics
12.4 Electrical Characteristics (Input Rectifier)
Item Unit
Rated Power (kVA)
120
Rated AC input voltage
1
VAC
380/400/415, 3-phase 4-wire (+PE) TN/TT/IT power
distribution system
Input voltage range
2
VAC
176 to 276 (full load)
132 to 176 (half load)
Frequency
2
Hz 50/60 (range: 40 to 70)
Power factor kW/kVA, full load (half load) 0.99
Input current A, rated
3
173
Total current harmonic distortion % 3
1
Rectifiers operate at any of the rated supply voltages and frequencies without further adjustment.
2
At 305 V input mains the UPS maintains the specified output voltage at rated load without discharging a battery.
3
IEC62040-3/EN50091-3: at rated load, input voltage is 400 V, battery remains fully charged.
Table 12.4 Rectifier AC Input (Mains)
172 Proprietary and Confidential ©2023 Vertiv Group Corp. 12 Specifications
Vertiv™ Liebert® APM2 30 to 120 kVA Modular UPS User Manual
