1. If Auto Recovery after EOD Enabling is enabled.
2. After the Auto Recovery after EOD Delay Time expires (the default delay is 10 minutes), the UPS restarts bypass,
then inverter. During the automatic recovery delay, the UPS will charge its batteries to provide a safety margin for
equipment shutdown if input power fails again.
NOTE: During the automatic restart process, manual startup is disabled. Automatic restart must be set by Vertiv's
authorized service engineer through Vertiv setting software.
6.9 Selecting Language
Use the following procedures to select the language:
1. Click the icon .
2. Click the icon .
3. Click the item of Display.
4. Click Display Properties.
5. As shown in Figure 6.19 below, click Language to set the language you need.
Figure 6.19 Setting Language
6 Single UPS Operation Proprietary and Confidential ©2023 Vertiv Group Corp. 119
Vertiv™ Liebert® APM2 30 to 120 kVA Modular UPS User Manual
