Name Drawing Name Drawing
Drill Wire cutting plier
Claw hammer Diagonal cutting plier
Insulating shoes Antistatic gloves
Electrician knife Cable tie
Insulating tape Insulating gloves
Crimping plier Heat shrinkable tube
Insulated torque
wrench
Torque screwdriver
Multimeter Clip-on ammeter
Table 3.1 Tools (continued)
3.4 Unpacking
Before unpacking the UPS and battery, inspect for any visual damage or signs of mishandling. Under the guidance of
authorized service engineer, follow the below steps to unpack the UPS and battery packages.
1. Remove the packing belts and honeycomb boards as shown in Figure 3.2 on the next page.
3 Mechanical Installation Proprietary and Confidential ©2023 Vertiv Group Corp. 23
Vertiv™ Liebert® APM2 30 to 120 kVA Modular UPS User Manual
