Vertiv™ NetSure™ Control Unit (NCU) User Manual
92
Figure 3.5 Settings Menu
To Select a Sub-Menu:
Press the UP and DOWN keys to
highlight the desired sub-menu.
Press the ENT key to enter the
selected sub-menu.
Note: Items marked with an “>” indicates there is a submenu.
Press ENT to view the submenu.
E
ENT
ESC
Basic Settings >
Charge >
Battery Test >
Batt Temp Mgmt >
Batt1 Settings >
Batt2 Settings >
Basic Settings >
Charge >
Battery Test >
Batt Temp Mgmt >
Batt1 Settings >
Batt2 Settings >
Batt Settings
Note: Certain line items in menu or menus
themselves appear if system is
equipped with function or function
is enabled.
The parameter values shown in ( ) are the
adjustment range or acceptable values.
Factory default settings are listed in the
NCU Configuration Drawing (C-dwg)
furnished with your system.
Num Batt Shunts:
2 (0 to 2)
Reset Batt Cap:
Yes (Yes)
Float Voltage:
53.5V (42 to 58)
EQ Voltage:
56.4V (42 to 58)
Curr Limit Mode:
Yes (Yes / No)
Batt Curr Limit:
0.10C10 (0.10C10 to 0.25C10)
Over Curr Lmt:
0.30C10 (0.30C10 to 1.00C10)
Auto EQ:
Yes (Yes / No)
TC Off When:
All Probes Fail (All Probes Fail / Any Probe Fails)
Test Volt Level:
45.0V (43.0 to 53.5)
End Test Volt:
45.2V (43.2 to 53.5)
End Test Time:
10min (10 to 1440)
EndTestCapacity:
73% (0 to 100)
RecordThreshold:
0.100V (0.1 to 1)
TempComp Sensor:
None
TempComp Center:
13deg.C (0 to 40)
Temp Comp Coeff:
71mV/deg.C (0 to 500)
Temp Comp Clamp:
Enabled (Enabled / Disabled)
Temp Comp Max V:
58.0V (42 to 58)
Temp Comp Min V:
52.0V (42 to 58)
BTRM TempSensor:
None
BTRM Action:
Disabled (Disabled / Lower Voltage)
BTRM Voltage:
48.0V (45 to 55)
Shunt Current:
300A (50 to 5000)
Shunt Voltage:
25 mV (1 to 150)
Rated Capacity:
50000Ah (40 to 50000)
Shunt Current:
300A (50 to 5000)
Shunt Voltage:
75 mV (1 to 150)
Rated Capacity:
600Ah (40 to 50000)
Basic Settings
Charge
Battery Test
Batt Temp Mgmt
Batt1 Settings
Batt2 Settings
ENT
ESC
E1
ENT
ESC
E2
ENT
ESC
E3
ENT
ESC
E4
ENT
ESC
E5
ENT
ESC
E6
Batt Settings >
To Change a Parameter:
Press the UP and DOWN keys to
move up and down list of parameters.
Press ENT to select the parameter.
Press the UP and DOWN keys to
change the parameter.
Press ENT to make the change.
Press ESC to cancel the change.
(None / Maximum / Average /
System T1 (bat) / System T2 (bat) / System T3 (bat) /
IB2-1 T1 (bat) / IB2-1 T2 (bat) /
EIB-1 T1 (bat) / EIB-1 T2 (bat) /
SMTemp1 T1 (bat) / ... / SMTemp1 T8 (bat) / ... /
SMTemp8 T1 (bat) / ... / SMTemp8 T8 (bat))
ENT
ENT
ENT
ENT
ENT
ENT
ESC
ESC
ESC
ESC
ESC
ESC
E1
E2
E3
E4
E5
E6
(None / Maximum / Average /
System T1 (bat) / System T2 (bat) / System T3 (bat) /
IB2-1 T1 (bat) / IB2-1 T2 (bat) /
EIB-1 T1 (bat) / EIB-1 T2 (bat) /
SMTemp1 T1 (bat) / ... / SMTemp1 T8 (bat) / ... /
SMTemp8 T1 (bat) / ... / SMTemp8 T8 (bat))
