Vertiv™ NetSure™ Control Unit (NCU) User Manual
19
2.3 Using the Local Keypad and Display
See also “Passwords and Privilege Levels” on page 20.
2.3.1 Local Menu Navigation Keys and Local Display
There are four (4) menu navigation keys and a local display located on the NCU’s front panel. Refer to Table 2.2 for the function of
the menu navigation keys. Refer to Figure 2.2 for location.
NOTE! When the local display is lit, if no button is pushed for eight (8) minutes, the backlight of the local display extinguishes
and the NCU returns to the Main Menu. Press any key to re-activate the local display.
Table 2.2 Local Menu Navigation Keys
Key Symbol Key Name Function
ESC Escape
Press this key to go back to a previous menu or to cancel
setting a parameter.
Press ESC and ENT together to reset the NCU,
then press ENT to accept or ESC to cancel.
ENT Enter
Press this key to go forward to the next menu, to select a
parameter to edit, or to validate a parameter setting change.

Up Arrow
Press the up or down arrow keys to scroll through the menus
or to change the value of a parameter.
--

Down Arrow
Press any key to silence an audible alarm.
2.3.2 Local Display Menus
Refer to “Local Display Menus” on page 85.
Navigating the Menus
To Select a Sub-Menu:
Press the UP and DOWN keys to highlight the desired sub-menu.
Press the ENT key to enter the selected sub-menu.
To Select a User and Enter a Password:
To select a User, use the UP and DOWN keys to move the cursor to the Select User field. Press ENT. Use the UP and DOWN keys to
select a User previously programmed into the NCU. Press ENT to select the User. Note that only Users programmed into the NCU
are shown. Users are programmed via the Web Interface.
To enter a password, use the UP and DOWN keys to move the cursor to the Enter Password field. Press ENT. Use the UP and DOWN
keys to choose a character. Press ENT to accept and move to the next character. Continue this process until all characters are
entered. Press ENT again to accept the password.
To Change a Parameter:
Press the UP and DOWN keys to move up and down the list of parameters.
Press ENT to select the parameter.
Press the UP and DOWN keys to change the parameter.
Press ENT to make the change. Press ESC to cancel the change.
