Vertiv™ NetSure™ Control Unit (NCU) User Manual
NOTE!
SOME SYSTEMS REQUIRE CHANGES TO THE NCU CONFIGURATION DURING FINAL TEST BEFORE BEING
SHIPPED. These systems are supplied with a USB memory device that contains a “SettingParam.tar” file as shipped. If
provided, the “SettingParam.tar” file has a seven-digit UIN (Unique Identification Number) preceding the “SettingParam.tar”
filename. The UIN identifies a “SettingParam.tar” file for use with a specific system. This file can be used to restore your
system to the configuration as shipped. Refer to “Reloading a Backed-Up NCU Configuration” on page 48 to reload the
supplied “SettingParam.tar” file.
TO RESTORE THESE SYSTEMS TO THE NCU CONFIGURATION AS SHIPPED, RESTORE DEFAULTS AS DESCRIBED ABOVE; THEN
RELOAD THE SUPPLIED "SETTINGPARAM.TAR" FILE.
2.9.60 Rebooting the Controller
NOTE!
The controller does not turn off any relay when the controller is reset/replaced. If the relay is active when the
controller is reset/replaced, it will stay active whether or not the alarm condition still exists. If possible, the alarm condition
should be cleared before the controller is reset/replaced. If the alarm is not cleared, after starting the controller, it may be
necessary to manually trigger an alarm condition to clear all alarm relays.
Local Menu Navigation:
At the Main Screen, press ENT and ESC at the same time to reset the NCU Controller.
Web Menu Navigation:
Advance Settings Menu / SW Maintenance Tab / Reboot Controller button.
2.9.61 Changing the Names of Items Displayed in the LCD and Web-Interface Menus
Local Menu Navigation:
none.
Web Menu Navigation:
Navigate to the appropriate tab in the Advance Settings menu. Press “Modify” and enter the signal name parameter(s). When done,
press “Set”.
Digital Inputs
Advance Settings Menu / DI Alarms Tab.
Relay Outputs
Advance Settings Menu / DO (relay) Tab.
Shunts
Advance Settings Menu / Shunts Tab.
Fuses
Advance Settings Menu / Fuse Tab.
2.9.62 Upgrading the Rectifiers Firmware
Rectifier firmware upgrade files or USB memory device must be supplied to you. If provided rectifier firmware upgrade files, copy the
files to a USB memory device. Place the USB memory device into the NCU USB port and follow the procedure below. If upgrading
rectifier firmware with a USB memory device other than a supplied USB memory device, the following USB memory device
specifications must be adhered to:
• USB 2.0 or below, 32G or less, formatted fat32 file system.
