Vertiv™ NetSure™ Control Unit (NCU) User Manual
42
2.9.44 Setting Digital Inputs
Local Menu Navigation:
None.
Web Menu Navigation:
Advance Settings Menu / DI Alarms Tab
2.9.45 Setting Battery Block and Battery Midpoint Monitoring (if equipped with an EIB
Assembly)
Local Menu Navigation:
None.
Web Menu Navigation:
Settings Menu / Battery Tab / and enter the following parameters.
Parameters
EIB-# Voltage Type
EIB-# Block In-Use Num
EIB-# Block Voltage Diff or Block Voltage Diff (Mid)
2.9.46 Setting External Shunts (connected to the EIB Assembly)
Local Menu Navigation:
None.
Web Menu Navigation:
Advance Settings Menu / Shunts Tab / EIB-# / press “Modify/View” and enter the following parameters. When done, press “Set”.
Parameters
Set As (Not Used, General, Load, Battery, Source)
Signal Full Name
Signal Abbr Name
Full Scale Current
Full Scale Voltage
Break Value (Device Rating)
High 1 Curr Limit Alarm (% of Breaker Value)
High 1 Curr Alarm Severity
High 1 Curr Alarm Relay
High 2 Curr Limit Alarm (% of Breaker Value)
High 2 Curr Alarm Severity
High 2 Curr Alarm Relay
