Vertiv™ NetSure™ Control Unit (NCU) User Manual
43
WEB Menu Navigation (for shunts set as battery):
See “Individual Battery Settings Page” on page 133.
Parameters
• EIB#Battery #, Rated Capacity
2.9.47 Setting External Shunts (connected to the SMDU+ Assembly)
Local Menu Navigation:
None.
Web Menu Navigation:
Advance Settings Menu / Shunts Tab / SMDUP # / press “Modify/View” and enter the following parameters. When done, press “Set”.
Parameters
• Set As (enabled, disabled)
• Signal Full Name
• Signal Abbr Name
• Full Scale Current
• Full Scale Voltage
• Break Value (Device Rating)
• High 1 Curr Limit Alarm (% of Breaker Value)
• High 1 Curr Alarm Severity
• High 1 Curr Alarm Relay
• High 2 Curr Limit Alarm (% of Breaker Value)
• High 2 Curr Alarm Severity
• High 2 Curr Alarm Relay
2.9.48 Setting Shunts (connected to the SMDU Assembly)
Local Menu Navigation:
None.
Web Menu Navigation:
Advance Settings Menu / Shunts Tab / SMDU # / press “Modify/View” and enter the following parameters. When done, press “Set”.
Parameters
• Set As (Not Used, General, Load, Battery, Source)
• Signal Full Name
• Signal Abbr Name
• Full Scale Current
• Full Scale Voltage
