Vertiv™ NetSure™ Control Unit (NCU) User Manual
to exceed the total capacity of the rectifiers in the existing power system (or shut down some of the rectifiers in the existing
power system if the capacity of the external dry load bank is not sufficient).
a) Verify that the NCU power system starts taking the additional load as soon as the total capacity of the rectifiers in the
existing power system is exceeded.
2.11 FIAMM SoNick (Sodium Nickel) Batteries Interface
If a special configuration file is furnished, the NCU has capability to receive status information sent from FIAMM SoNick (Sodium
Nickel) batteries. Refer to the following for FIAMM SoNick (Sodium Nickel) battery interface notes.
2.11.1 FIAMM Battery Installation and User Instructions
The following instructions apply only when FIAMM 48TL200 batteries are used in a NetSure 721 Power System equipped with an NCU
FIAMM battery interface configuration.
Notes:
• NCU FIAMM battery configuration cannot be used with, or mixed with, batteries of other manufacturing types.
• A specific FIAMM NCU configuration is required in order for the controller to actively display FIAMM battery monitoring
parameters.
Required FIAMM Documentation
The following FIAMM instructional documentation is to be obtained directly from FIAMM.
Note that the following instructions were developed using the FIAMM documents and corresponding revision level as listed below.
• FIAMM Technical Manual, ‘Installation & Operating Instructions_48TL200_12-2014’
• FIAMM Technical Bulletin, ‘48TL200 Modbus Protocol’, (Revision 5, Issue Date 21/05/2012)
• FIAMM User Manual, ‘48TL200 SMC Monitor’, (Revision 0, Issue Date 27/08/2012)
• FIAMM Technical Bulletin, ‘SMC Battery Software Interface’, (Revision 0.0, Issue Date 3-2014)
FIAMM Battery SMCMonitor200 Software
Installation and monitoring instructions of the FIAMM batteries using FIAMM SMCMonitor200. Software is located in the FIAMM
Technical Bulletin, ‘SMC Battery Software Interface’, (Revision 0.0, Issue Date 3-2014). Contact FIAMM for any questions regarding
the SMCMonitor200 operation.
NOTE!
FIAMM SMCMonitor200 software is used exclusively to directly monitor FIAMM batteries via a User’s computer. The
monitoring software has no application with the NCU Controller.
Following software is required for SMCMonitor200 communication for the User’s computer, and is available from FIAMM.
• Virtual Com-Port Driver Installation
• SMCMonitor200 1.5.3 Software Folder,
- Containing Folders: Backup, Config, Log, XML
- Containing Files: SMC Battery Software Interface_So-Nick-48TL200.pdf; SMCMonitor200.exe
Installation Requirements for NCU Monitoring of FIAMM Battery(s)
The setup installation for monitoring of FIAMM batteries using the Vertiv NCU requires the following procedures.
1. Install RS485 conductors in parallel between the NetSure 721 and each of the FIAMM batteries.
