Vertiv™ NetSure™ Control Unit (NCU) User Manual
3.11 Battery Menu
The Battery Menu can be accessed from the Main Menu as shown in Figure 3.10. The actual display of the Battery Menu is dependent
on the NCU configuration.
Figure 3.10 Battery Menu
Rect Cap Used: 22.3 %
Comp T
emp: 25deg.C >
Battery Menu
Press the UP and DOWN keys to highlight
the desired Menu graphic in the Main Menu.
Press the ENT key to enter the selected menu.
ENT
UP / DOWN
UP / DOWN
ENT
ESC
ENT
ESC
ESC
ESC
ESC
UP / DOWN
ESC
UP / Down for
more screens.
Note: Items marked with an “>” indicates there is a submenu.
Press ENT to view the submenu.
To Next Page
