Vertiv™ NetSure™ Control Unit (NCU) User Manual
12:17.00… 54.4…
2.13.3 EXAMPLE
The controller can be accessed at 192.168.1.2.
Request
http://192.168.1.2/data.cgi?stime=1404061200&etime=140464799 ukey1=123, ukey2=abc, ukey3=foobar
Response
”DateTime”, “Epoch Time”, “Temperature”, “Supply Temp”, “OAT Temp”, “Temp Code” , ”UserKey1”, ”UserKey2”, ”UserKey3”
7/1/2014 19:07,1404241623,74.6,73.3,70.9,71.3,97,123,abc,foobar
7/1/2014 19:08,1404241723,75.6,74.3,71.9,72.3,97,123,abc,foobar
7/1/2014 19:10,1404241823,76.6,75.3,72.9,73.3,97,123,abc,foobar
2.14 Resolving Alarms
Table 2.3 lists the alarms that are shown in the Web Interface Advance Settings Menu under the Alarms Tab. These are also the
possible alarms that display in the alarm screens on the local display and Web Interface. Table 2.3 also provides guidelines for fixing
the condition that caused the alarm.
NOTE!
These instructions describe the complete functionality of the controller. Some functionality is dependent on
hardware connected to the controller. Some alarms listed may not display in your system or may be named differently. Refer
to the NCU Configuration Drawing (C-drawing) furnished with your system.
Refer also to the NCU Configuration Drawing (C-drawing) furnished with your system for the factory default “Alarm Severity Level”
settings and “Alarm Relay” mapping to the available alarms.
Rectifier Lost Alarm Description: The rectifier lost alarm occurs if the NCU updates the inventory and finds that the number of
rectifiers is different. Two conditions cause the NCU to update its inventory. The first condition is if the NCU reboots. Every time the
NCU starts up it updates the inventory. The second condition is when a rectifier is installed in the system. This causes the NCU to
update its inventory. When a rectifier is installed, the NCU re-inventories which clears any “Rect Comm Fail” alarms. The NCU then
finds the inventory doesn’t match what it used to and a “Rectifier Lost” alarm is activated.
Table 2.3 Available Alarms
Alarm Name Alarm Description Action to Correct
Power System Alarms
Supervision Unit Fail Controller self-detection test fails. Replace the controller.
CAN Communication Failure
CAN bus communications failure.
No devices communicating on CAN bus.
Check communications cables.
Outgoing Alarms Blocked
Alarm relays are forced in the "off" state and alarms are
blocked from changing the relay state.
Verify why controller setting was changed before
changing back.
Maintenance Time Limit Alarm Controller issues a maintenance alarm.
Perform routine maintenance and reset maintenance
timer.
Config Error (Backup Config) Configuration error 1.
Reload the "SettingParam.tar" file.
Config Error (Default Config) Configuration error 2.
