Vertiv™ NetSure™ Control Unit (NCU) User Manual
259
Figure 9.1 NCU Digital Input and Relay Output Connections
NO NCCNO NCC NO NCCNO NCC
Relay
Outputs
Relay
Outputs
Digital
Inputs
Digital
Inputs
DO 4DO 3DO 2DO 1 DI 4DI 3DI 2DI 1
+ - + - + - + -
