5-16 Videojet DataFlex 6530 Operator Manual - Rev AA
CLARiTY Operating System
Touch Printhead Health on the Printhead screen to access the printhead health parameters
(Figure 5-11).
The Printhead Health screen provides access to the following parameters:
Option Description
Health graph The printhead health graph.
Printhead ID The printhead ID.
Printhead Resistance The printhead resistance. The printhead
resistance value matches the drive
electronics of the printer to the resistance
characteristics of the printhead.
Total Distance Printed The total distance printed in km.
Manufacturer’s Password Enter the manufacturer’s password to enable
higher level options.
Table 5-12: Printhead Health Screen Description
Figure 5-11: Printhead Health Screen
