5-30 Videojet DataFlex 6530 Operator Manual - Rev AA
CLARiTY Operating System
Using the Communications Screen
Touch Communications on the Control screen to access the parameters (Figure 5-27).
The Communications screen displays the following parameters:
Option Description
Communication Port 1 The status of serial port, including the baud rate and usage.
Refer “Using the Communication Port 1 Screen” on page 5-33.
TCP/IP The configuration and status of the printer’s network port.
Refer “Using the TCP/IP Screen” on page 5-34
Table 5-21: Communications Screen Description
Figure 5-26: Communications Screen
