Chapter 4 Deployment of the CPU 21x-2BT10 with TCP/IP Manual VIPA CPU 21x
4-30 HB103E - Rev. 05/45
The register addresses shows the relevant local and partner address
information as suggestion values. Depending on the communication type
you may leave the address information unspecified.
The following table shows the combination options with the different
operating modes:
Connection partner Connection type Conn. Establ. Connection Operating mode
TCP / ISO-on-TCP active/passive Specified in NetPro
(in recent project)
UDP -
specified SEND/RECEIVE
active specified SEND/RECEIVE
part specified
(Port)
TCP / ISO-on-TCP
passive
unspecified
SEND/RECEIVE
FETCH PASSIV
WRITE PASSIV
Unspecified in NetPro
(in recent project)
UDP - specified SEND/RECEIVE
Unspecified in NetPro
(in "unknown project") active
unspecified
(connection
name)
SEND/RECEIVE
TCP / ISO-on-TCP
passive
unspecified
(connection
name)
SEND/RECEIVE
FETCH PASSIV
WRITE PASSIV
UDP -
unspecified
(connection
name)
SEND/RECEIVE
All Broadcast stations UDP -
specified (Port,
Broadcast addr)
SEND
All Multicast stations UDP -
specified (Port,
Multicast group)
SEND/RECEIVE
A connection is specified by the local and partner connection end point. At
the project engineering of connections ports/TSAPs must be congruent
crosswise. Depending on the protocol the following parameters define a
connection end point:
IP address Station A IP address Station B
partner TSAP → → local TSAP
local TSAP ←
ISO-on-TCP
connection
← partner TSAP
IP address Station A IP address Station B
partner Port → → local Port
local Port ←
TCP
connection
← partner Port
IP address Station A IP address Station B
partner Port → → local Port
local Port ←
UDP
connection
← partner Port
ISO-on-TCP supports TSAP lengths (Transport Service Access Point) of
1...16Byte. You may enter the TSAP in ASCII or hexadecimal format. The
calculation of the length happens automatically.
Ports res. port addresses are defining the access point to the user
application within the station/CPU. These must be unambiguous. A port
address should be within the range of 2000...65535. Foreign and local
ports may only be identical with one connection.
Addresses
Address parameter
TSAP
Port
