Chapter 5 Deployment CPU 21x-2BT02 with H1 / TCP/IP Manual VIPA CPU 21x
5-12 HB103E - Rev. 05/45
Transfer CP project
In the "network" window mark the station to be transfered.
• Activate the online functions via
.
• If there is still an online connection to the CP, set the CP into software
STOP via
an start transfer with .
Otherwise set "IP protocol" under
and type the IP address
172.16.192.11 (delivery address).
• Establish a connection via
.
• Set the CP into software STOP via
and start the transfer into the
CP using
.
If a request for a NCS file appears, you forgot to choose the CP in the
network window! Return to the last step, choose the correct setting and
start the transfer again.
• Since the data are stored unsecured in the RAM, you have to store
these durable in the Flash ROM using
. With each further flash
command the date will be replaced.
• As soon as the transfer has finished, reboot the CP via
.
Now the CP is online available with the assigned IP address.
