Chapter 8 Deployment CPU 21xCAN Manual VIPA CPU 21x
8-32 HB103E - Rev. 05/45
Index Sub-
index
Name Type Attr. Map. Default value Meaning
0x6200 0x00 8bit digital
output block
Unsigned8 ro N 0x01 Number of available digital
8-bit output blocks
0x01 1
st
output
block
Unsigned8 rw Y 1st digital output block
... ... ... ... ... ... ...
0x40 64
th
output
block
Unsigned8 rw Y 64 nd digital output block
Index Sub-
index
Name Type Attr. Map. Default value Meaning
0x6300 0x00 16bit digital
input block
Unsigned8 ro N Depending on
the compo-
nents fitted
Number of available digital
16-bit output blocks
0x01 1
st
output
block
Unsigned16 rw N 1
st
digital output block
... ... ... ... ... ... ...
0x20 32
nd
output
block
Unsigned16 rw N 32
nd
digital output block
Index Sub-
index
Name Type Attr. Map. Default value Meaning
0x6320 0x00 32bit digital
input block
Unsigned8 ro N Depending on
the compo-
nents fitted
Number of available digital
32-bit output blocks
0x01 1
st
output
block
Unsigned32 rw N 1st digital output block
... ... ... ... ... ... ...
0x10 16
th
output
block
Unsigned32 rw N 16 digital output block
8bit Digital
outputs
16bit Digital
outputs
32bit Digital
outputs
