Manual VIPA CPU 21x Chapter 8 Deployment CPU 21xCAN
HB103E - Rev. 05/45 8-31
Index Sub-
index
Name Type Attr. Map. Default value Meaning
0x6000 0x00 8bit digital
input block
Unsigned8 ro N 0x01 Number of available digital
8-bit input blocks
0x01 1
st
input
block
Unsigned8 ro Y 1
st
digital input block
... ... ... ... ... ... ...
0x40 64
th
input
block
Unsigned8 ro Y 64
th
digital input block
Index Sub-
Index
Name Type Attr. Map. Default value Meaning
0x6100 0x00 16bit digital
input block
Unsigned8 ro N depending on
the fitted
components
Number of available digital
16-bit input blocks
0x01 1
st
input
block
Unsigned16 ro N 1
st
digital input block
... ... ... ... ... ... ...
0x20 32
nd
input
block
Unsigned16 ro N 32
nd
digital input block
Index Sub-
index
Name Type Attr. Map. Default value Meaning
0x6120 0x00 32bit digital
input block
Unsigned8 ro N depending on
the compo-
nents fitted
Number of available digital
32-bit input blocks
0x01 1
st
input
block
Unsigned32 ro N 1
st
digital input block
... ... ... ... ... ... ...
0x10 16
th
input
block
Unsigned32 ro N 16 digital input block
8bit Digital inputs
16bit Digital inputs
32bit Digital inputs
