Chapter 8 Deployment CPU 21xCAN Manual VIPA CPU 21x
8-30 HB103E - Rev. 05/45
Index Sub-
Index
Name Type Attr. Map. Default value Meaning
0x1F82 0x00 RequestNMT Unsigned32 rw N 0x00000000
If a totally automatic start of the stack is not wanted, the functionalities:
• Status change
• Start of the guarding
• Configuration via CMT
can be also executed at request for every node. The request always
happens via objects in the object directory.
The switch of the communication state of all nodes in the network
(including the local slaves) happens via the entry 1F82h in the local object
directory:
Subindex 0 has the value 128.
Subindex x (with x=1..127): Initiates the NMT service for nodes with Node ID x.
Subindex 128: Initiates NMT service for all nodes.
At write access, the wanted state is given as value.
State Value
Prepared 4
Operational 5
ResetNode 6
ResetCommunication 7
PreOperational 127
Index Sub-
index
Name Type Attr. Map. Default value Meaning
0x1F83 0x00 RequestGuarding Unsigned32 rw N 0x00000000
Subindex 0 has the value 128.
Subindex x (with x=1..127): Initiates guarding for the slave with Node ID x.
Value Write Access Read Access
1 Start Guarding Slave actually is guarded
0 Stop Guarding Slave actually is not guarded
Subindex 128: Request Start/Stop Guarding for all nodes.
Request NMT
Request Guarding
