VIVOTEK
User's Manual - 15
O
I
O
I
Detected object
Detection area
Tracking end point
Detection line
Object tracking line
Start point
Found physical characteristics
of humans & starts tracking...
[45] H=181
5. Below are the conguration elements for operating the SC8131 3D camera: .
The counting takes place when a moving object appears in the detection area and moves
across the detection line.
