Vivotek SC8131 - Page 17

VIVOTEK
User's Manual - 17
O
I
Detection area
Detection line
Not enough space to recognize
objects....
O
I
8. An effective counting requires an object to be detected, and then moves across the
detection line. Avoid setting the line too close to the edge of detection area.
O
I
Detection area
Detection line
The start and end points
take shape across the line.
O
I
9. By drawing the line slightly away from the place where customers make their
appearance allows enough space for recognition to take place. A start and an end point
across the line enable the movement to be considered as a count.
The stop point is where the object vanishes from the scene.
