Keyset Mode 2-213
Features and Operation
STARPLUS STSe - Programming & Operations Manual August 2005
2. Enter the range of fixed station numbers (100-149) to be programmed. If only one station
is being programmed, enter that number twice, e.g., [100 100].
-or-
Enter a valid flexible number (100-8999) to be programmed.
3. Press HOLD to save the entry. A confirmation tone sounds and the display updates.
Flexible button #19 is lit. The display updates to reflect current programming for Page A:
4. Press button #20. The display updates to reflect current programming for Page B.
5. Press the KEYSET MODE flexible button (Button #12). The following message displays:
6. Enter a valid number (0-6) to change the mode of a digital telephone:
[0] = Inactive Mode (normal mode without CTI box)
[1] = PC Phone (Discovery Desktop) Mode at 4800 baud
[2] = ATD Command Mode at 4800 baud
[3] = ATH Command Mode at 4800 baud
[4] = CKTU Mode at 4800 baud
[5] = SPI Mode at 4800 baud
[6] = TAPI Mode at 4800 baud
7. Press HOLD to save the entry. A confirmation tone sounds and the display updates.
DEFAULT … Keyset is set for Inactive Mode.
If HOLD is pressed without entering a station range, all stations are selected.
Flash 50 - Fixed Numbers Flash 51 - Flexible Numbers
XXX - XXX PAGE A
ENTER BUTTON NUMBER
SXXX PAGE A
ENTER BUTTON NUMBER
XXX-XXX = fixed station range XXX = 3- or 4-digit flexible number
Flash 50 - Fixed Numbers Flash 51 - Flexible Numbers
XXX - XXX PAGE B
ENTER BUTTON NUMBER
SXXX PAGE B
ENTER BUTTON NUMBER
XXX-XXX = fixed station range XXX = 3- or 4-digit flexible number
KEYSET MODE 0-6
INACTIVE MODE
