2-214 Keyset Mode
Features and Operation
STARPLUS STSe - Programming & Operations Manual August 2005
Operation
At an idle station:
1. Dial the Keyset Mode code [648] on the dial pad,
-or-
Press the preprogrammed KEYSET MODE button, the following displays:
2. Press [
] to scroll through the keyset modes.
3. Press [#] to scroll through the baud rates.
4. Press the HOLD button to save the desired entries.
SINGLE LINE TELEPHONE
Not applicable
Conditions
» Telephone must be in AT command mode to process AT commands.
» CTI information is still sent out the RS-232 port in AT command mode.
» The ATD command is always accepted by the telephone while it is in the AT command
mode. ATHX is accepted only if enabled.
» ATZ is always enabled if station is in the ATD or ATH command mode.
» ATD accepts W to indicate a pause command (ATDT9W9982200).
» ATH or ATH0 causes an on hook event. ATH1 must be specified to go off hook.
» AT or ATZX (X = 0 or 1) is the modem reset/initialize command. When these commands
are sent to the keyset, it returns OK in ASCII format.
» Only one station at a time can be programmed when using a flexible station number.
» When in Flash 51 programming, if you press HOLD without specifying a flexible number
to be programmed, you will get the station that is in port/station 100.
» Either the Wanderer or the CTI module can be connected to a station, but not both
simultaneously.
INACTIVE 2400
MODE= SAVE=HOLD BAUD=#
