Weber Markoprint integra PP108 - Component Listing

List of Accessories and Spare parts 40075165 Markoprint integra PP108
Page 88 of 104 GB
Pos.
Figure
Assembly
Description
Order no.
1
Mounting bracket
Compact
For a fixing on a conveyor from the
side.
71800027
2
Mounting bracket
Top
For a fixing on a conveyor from the
top.
IN
PREPARA
RATION
3
Sensor (NPN),
10…30V DC
Standard M12
Incl. 5.0 m connecting cable (M12 to
15pin Sub-D) and universal holder
72800002
Sensor (NPN) M8,
with bracket for
print head
mounting
Incl. connecting cable (M8 to 15pin
SUB-D) and bracket for print head
mounting
72801075
4
Protection plate
with sensor (NPN)
Incl. connecting cable (M8 to 15pin
SUB-D)
72801076
5
Shaft encoder
Spring arm holder
Push-pull output, 5,000 pulses/rev,
with spring arm and friction wheel,
incl. mounting holder and
connecting cable (M12 to 15pin
Sub-D)
SPLITTER CABLE NECESSARY
72801042
6
Rotary encoder
Angle holder
Push-pull output, 5,000 pulses/rev.,
with angle holder, friction wheel and
connecting cable (M12 to 15pin
Sub-D)
SPLITTER CABLE NECESSARY
72801041
7
USB-data stick
Version 1
72901203
