Data, transport, start-up
8-2 Profimat 23 E
Space required by the machine
The installation diagram supplied with the order
confirmation contains the definitive machine data
and dimensions. It should always be consulted
whenever the machine is transported, installed
and connected.
The actual space required by the machine is
calculated as follows:
Outside dimensions of machine L x W x H
(see installation diagram)
+ Swivel range of doors, flaps, assemblies
+ Space required for setting up
+ Space required for maintenance work
+ Space required for workplaces
+ Material handling systems for workpiece
infeed / guides
+ Safety zone (national regulations)
+ Space required for peripherals (emergency
exits, raw timber store, etc.)
+ The machine must be set up in such a way
that there is no risk of being crushed
between moving parts and other fixed
machines, parts of buildings, stacks of
material, etc.
+ Space for the maximum timber length
before and after the machine
A minimum distance of 0.5 metres must be
allowed between the longest workpiece and
immovable surrounding elements
= Space required for machine
Append the installation diagram supplied with the
order confirmation, for example, here.
