Weinig Profimat 23 E - Foundation and Shipping Data

Tech. Dok. / L23 880 02 / 05.99.01 © MICHAEL WEINIG AG
Data, transport, start-up
8-3Profimat 23 E
Size of foundations
Position of machine feet .............................................................. See installation diagram
Static load on machine feet for strength of foundations ............. See installation diagram
Shipping data
Shipping weight / dimensions (incl. packaging)............................. See freight documents
Shipping weight (without tools) ..................................................... See installation diagram
Feed rollers
Feed rollers, steel (dia., width, bore) ....................................... Dia.140 x 50 x dia. 35 mm
Feed rollers, rubber .................................................................. Dia.140 x 50 x dia. 35 mm
Cup rollers, steel ................................................................... Dia.140 x 16.2 x dia. 35 mm
Material
Permissible materials ............................ Timber and wood substitutes, without impurities
Tools, general
Permissible tools............................................................................Balanced, stress-tested,
................................................................................suitable for mechanical feed,
.......................................................................suitable for speeds up to 6000 rpm
All saw blades and cutters must meet the safety requirements of pr EN 847-1.
Electrical connection
Total connected load, min./max. ................................................. See installation diagram
Power requirement................................................ See order confirmation for motor sizes
Current, operating voltage, frequency ................................Rating plate in control cabinet
Connected cross-section on installation side ......................Rating plate in control cabinet
Short-circuit-protection on installation side .......................Rating plate in control cabinet
Pneumatic connection
Nominal pressure .......................................................................................8 bar (113 psig)
Operating pressure, min./max................................................... 6 bar/10 bar (85/141 psig)
Dust extraction connection
Air flow rate, air requirement per spindle ................................... See installation diagram
Number of extractor hoods, additional connection diameters ..... See installation diagram
Total air requirement ......................... Sum of the individual air requirements per spindle
