Woodward HighPROTEC - Signals of the Digital Inputs and Logic

General Lists
Signals of the Digital Inputs and Logic
The following list comprises the signals of the Digital Inputs and the Logic. This list is used in various protective
elements.
Name Description
-.- No assignment
DI Slot X1.DI 1 Signal: Digital Input
DI Slot X1.DI 2 Signal: Digital Input
DI Slot X1.DI 3 Signal: Digital Input
DI Slot X1.DI 4 Signal: Digital Input
DI Slot X1.DI 5 Signal: Digital Input
DI Slot X1.DI 6 Signal: Digital Input
DI Slot X1.DI 7 Signal: Digital Input
DI Slot X1.DI 8 Signal: Digital Input
DI Slot X5.DI 1 Signal: Digital Input
DI Slot X5.DI 2 Signal: Digital Input
DI Slot X5.DI 3 Signal: Digital Input
DI Slot X5.DI 4 Signal: Digital Input
DI Slot X5.DI 5 Signal: Digital Input
DI Slot X5.DI 6 Signal: Digital Input
DI Slot X5.DI 7 Signal: Digital Input
DI Slot X5.DI 8 Signal: Digital Input
DI Slot X6.DI 1 Signal: Digital Input
DI Slot X6.DI 2 Signal: Digital Input
DI Slot X6.DI 3 Signal: Digital Input
DI Slot X6.DI 4 Signal: Digital Input
DI Slot X6.DI 5 Signal: Digital Input
DI Slot X6.DI 6 Signal: Digital Input
DI Slot X6.DI 7 Signal: Digital Input
DI Slot X6.DI 8 Signal: Digital Input
DNP3.BinaryOutput0 Virtual Digital Output (DNP). This corresponds to a virtual binary input of the
protective device.
DNP3.BinaryOutput1 Virtual Digital Output (DNP). This corresponds to a virtual binary input of the
protective device.
DNP3.BinaryOutput2 Virtual Digital Output (DNP). This corresponds to a virtual binary input of the
protective device.
DNP3.BinaryOutput3 Virtual Digital Output (DNP). This corresponds to a virtual binary input of the
protective device.
DNP3.BinaryOutput4 Virtual Digital Output (DNP). This corresponds to a virtual binary input of the
protective device.
DNP3.BinaryOutput5 Virtual Digital Output (DNP). This corresponds to a virtual binary input of the
protective device.
