Woodward HighPROTEC - Order Code

Order Code
Order Code
Generator Differential Protection
(Version 2 with USB, enhanced communication options
and new front plate)
MCDGV4 -2
Digital
Inputs
Binary
output relays
Analog
Inputs/Outputs
Housing
Large
display
16 11 0/0 B2 X A
8 11 2/2 B2 X B
24 11 0/0 B2 X C
16 16 0/0 B2 X D
Hardware variant 2
Phase Current 5 A/1 A, Ground Current 5 A/1 A 0
Phase Current 5 A/1 A, Sensitive Ground Current 5 A/1 A 1
Housing and mounting
Door mounting A
Door mounting 19” (flush mounting) B
Communication protocol
Without protocol A
Modbus RTU, DNP3.0, IEC60870-5-103, RS485/terminals B*
Modbus TCP, DNP3.0, Ethernet 100 MB/RJ45 C*
Profibus-DP, optic fibre D*
Profibus-DP, RS485/D-SUB E*
Modbus RTU, IEC60870-5-103, optic fiber F*
Modbus RTU, IEC60870-5-103, RS485/D-SUB G*
IEC61850, DNP3.0, Ethernet 100MB/ RJ45 H*
IEC60870-5-103, Modbus RTU, DNP3.0 RTU | RS485/terminals
Modbus TCP, DNP3.0 TCP/UDP | Ethernet 100 MB/RJ45
I*
IEC61850, Modbus TCP, DNP3.0 TCP/UDP | Optical Ethernet 100MB/LC duplex connector K*
Modbus TCP, DNP3.0 TCP/UDP | Optical Ethernet 100MB/LC duplex connector L*
IEC60870-5-103, Modbus RTU, DNP3.0 RTU | RS485/terminals
IEC61850, Modbus TCP, DNP3.0 TCP/UDP | Ethernet 100 MB/RJ45
T*
Harsh Environment Option
None A
Conformal Coating B
Available menu languages
Standard English/German/Spanish/Russian/Polish/Portuguese/French/Romanian
3 MCDGV4 DOK-HB-MCDGV4-2E
