Woodward HighPROTEC - Power - Measured Values

Measuring Values
Power - Measured Values
Value Description Menu path
S Measured Value (Calculated): Apparent power
(fundamental)
[Operation
/Measured Values
/Power]
P Measured value (calculated): Active power (P- = Fed
Active Power, P+ = Consumpted Active Power)
(fundamental)
[Operation
/Measured Values
/Power]
Q Measured value (calculated): Reactive power (Q- =
Fed Reactive Power, Q+ = Consumpted Reactive
Power) (fundamental)
[Operation
/Measured Values
/Power]
cos phi Measured value (calculated): Power factor: Sign
Convention: sign(PF) = sign(P )
[Operation
/Measured Values
/Power]
Wp+ Positive Active Power is consumed active energy [Operation
/Measured Values
/Energy]
Wp- Negative Active Power (Fed Energy) [Operation
/Measured Values
/Energy]
Wq+ Positive Reactive Power is consumed Reactive Energy [Operation
/Measured Values
/Energy]
Wq- Negative Reactive Power (Fed Energy) [Operation
/Measured Values
/Energy]
Ws Net Absolute Apparent Power Hours [Operation
/Measured Values
/Energy]
Wp Net Absolute Active Power Hours [Operation
/Measured Values
/Energy]
Wq Net Absolute Reactive Power Hours [Operation
/Measured Values
/Energy]
246 MCDGV4 DOK-HB-MCDGV4-2E
