Woodward HighPROTEC - System Module Input States

Device Parameters
System Module Input States
Name Description Assignment via
Ack LED-I Module input state: LEDs acknowledgement by
digital input
[Device Para
/Acknowledge]
Ack BO-I Module input state: Acknowledgement of the binary
Output Relays
[Device Para
/Acknowledge]
Ack Scada-I Module input state: Acknowledge Scada via digital
input. The replica that SCADA has got from the
device is to be reset.
[Device Para
/Acknowledge]
PS1-I State of the module input respectively of the signal,
that should activate this Parameter Setting Group.
[Protection Para
/PSet-Switch]
PS2-I State of the module input respectively of the signal,
that should activate this Parameter Setting Group.
[Protection Para
/PSet-Switch]
PS3-I State of the module input respectively of the signal,
that should activate this Parameter Setting Group.
[Protection Para
/PSet-Switch]
PS4-I State of the module input respectively of the signal,
that should activate this Parameter Setting Group.
[Protection Para
/PSet-Switch]
Lock Settings-I State of the module input: No parameters can be
changed as long as this input is true. The parameter
settings are locked.
[Field Para
/General Settings]
Internal test
state
Auxiliary state for testing purposes. []
481 MCDGV4 DOK-HB-MCDGV4-2E
