Field Parameters
Field Parameters – Voltage Related
Parameter Description Setting range Default Menu path
VT pri Nominal voltage of the Voltage
Transformers at the primary side. The phase
to phase voltage is to be entered even if the
load is in delta connection.
60 - 500000V 10500V [Field Para
/VT]
VT sec Nominal voltage of the Voltage
Transformers at the secondary side. The
phase to phase voltage is to be entered
even if the load is in delta connection.
60.00 -
600.00V
100V [Field Para
/VT]
VT con This parameter has to be set in order to
ensure the correct assignment of the
voltage measurement channels in the
device.
Phase to Phase,
Phase to
Ground
Phase to
Ground
[Field Para
/VT]
EVT pri Primary nominal voltage of the e-n winding
of the voltage transformers, which is only
taken into account in the direct
measurement of the residual voltage (GVT
con=measured/broken delta).
60 - 500000V 10500V [Field Para
/VT]
EVT sec Secondary nominal voltage of the e-n
winding of the voltage transformers, which
is only taken into account in the direct
measurement of the residual voltage.
35.00 -
600.00V
100V [Field Para
/VT]
V Block f Threshold for the release of the frequency
stages
0.15 - 1.00Vn 0.5Vn [Field Para
/General
Settings]
V Sync The fourth measuring input of the voltage
measuring card measures the voltage that
is to be synchronized.
L1,
L2,
L3,
L12,
L23,
L31
L12 [Field Para
/VT]
delta phi -
Mode
The delta phi element (vector surge) trips, if
the permissable voltage angle shift (delta
phi) of the three measured voltages (phase-
ground or phase-phase) in: one phase, two
phases or within all phases is exceeded.
one phase,
two phases,
three phases
two phases [Field Para
/VT]
490 MCDGV4 DOK-HB-MCDGV4-2E
