Field Parameters
Parameter Description Setting range Default Menu path
IL1, IL2, IL3
Cutoff Level
The Current shown in the Display or within
the PC Software will be displayed as zero, if
the Current falls below this Cutoff Level.
This parameter has no impact on recorders.
0.0 - 0.100In 0.005In [Device Para
/Measurem
Display
/CT Ntrl]
IG meas Cutoff
Level
The measured Earth Current shown in the
Display or within the PC Software will be
displayed as zero, if the measured Earth
Current falls below this Cutoff Level. This
parameter has no impact on recorders.
0.0 - 0.100In 0.005In [Device Para
/Measurem
Display
/CT Ntrl]
IG calc Cutoff
Level
The calculated Earth Current shown in the
Display or within the PC Software will be
displayed as zero, if the calculated Earth
Current falls below this Cutoff Level. This
parameter has no impact on recorders.
0.0 - 0.100In 0.005In [Device Para
/Measurem
Display
/CT Ntrl]
I012 Cutoff
Level
The Symmetrical Component shown in the
Display or within the PC Software will be
displayed as zero, if the Symmetrical
Component falls below this Cutoff Level.
This parameter has no impact on recorders.
0.0 - 0.100In 0.005In [Device Para
/Measurem
Display
/CT Ntrl]
489 MCDGV4 DOK-HB-MCDGV4-2E
