Woodward HighPROTEC - Energy Counter; Global Parameters of the Energy Counter Module; Direct Commands of the Energy Counter Module; Signals of the Energy Counter Module (States of the Outputs)

Energy Counter
Energy Counter
PQSCr
Global Parameters of the Energy Counter Module
Parameter Description Setting range Default Menu path
S, P, Q Cutoff
Level
The Active/Reactive/Apparent Power shown
in the Display or within the PC Software will
be displayed as zero, if the absolute value of
the corresponding Power falls below this
Cutoff Level. This parameter has no impact
on recorders.
0.0 - 0.100Sn 0.005Sn [Device Para
/Measurem
Display
/Power]
Power Units Power Units Power Auto
Scaling,
kW/kVAr/kVA,
MW/MVAr/MVA,
GW/GVAr/GVA
Power Auto
Scaling
[Device Para
/Measurem
Display
/General
Settings]
Energy Units Energy Units Energy Auto
Scaling,
kWh/kVArh/kVA
h,
MWh/MVArh/MV
Ah,
GWh/GVArh/GV
Ah
MWh/MVArh/
MVAh
[Device Para
/Measurem
Display
/General
Settings]
Direct Commands of the Energy Counter Module
Parameter Description Setting range Default Menu path
Res all Energy
Cr
Reset of all Energy Counters inactive,
active
inactive [Operation
/Reset]
Signals of the Energy Counter Module (States of the Outputs)
Signal Description
Cr Oflw Ws Net Signal: Counter Overflow Ws Net
Cr Oflw Wp Net Signal: Counter Overflow Wp Net
Cr Oflw Wp+ Signal: Counter Overflow Wp+
