Installation and Connection
Slot X103: Data Communication
Rear side of the device (Slots)
The data communication interface in the X103 slot is dependent on the ordered device type. The scope of functions
is dependent on the type of data communication interface.
Available assembly groups in this slot:
RS485 Terminals for Modbus, DNP and IEC
Fiber Optics Interface for Modbus, DNP and IEC
Fiber Optics Interface for Profibus
D-SUB Interface for Modbus, DNP and IEC
D-SUB Interface for Profibus
Fiber Optics Interface for Ethernet
The available combinations can be gathered from the ordering code.
90 MCDGV4 DOK-HB-MCDGV4-2E
