Woodward HighPROTEC - Direct Commands of the Protection Module; Global Protection Parameters of the Protection Module

Module: Protection (Prot)
Direct Commands of the Protection Module
Parameter Description Setting range Default Menu path
Res FaultNo a
GridFaultNo
Resetting of fault number and grid fault
number.
inactive,
active
inactive [Operation
/Reset]
Global Protection Parameters of the Protection Module
Parameter Description Setting range Default Menu path
Function Permanent activation or deactivation of
module/stage.
inactive,
active
active [Protection
Para
/Global Prot
Para
/Prot]
ExBlo Fc Activate (allow) the external blocking of the
global protection functionality of the device.
inactive,
active
inactive [Protection
Para
/Global Prot
Para
/Prot]
ExBlo1 If external blocking of this module is
activated (allowed), the global protection
functionality of the device will be blocked if
the state of the assigned signal becomes
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/Prot]
ExBlo2 If external blocking of this module is
activated (allowed), the global protection
functionality of the device will be blocked if
the state of the assigned signal becomes
true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/Prot]
Blo TripCmd Permanent blocking of the Trip Command of
the entire Protection.
inactive,
active
inactive [Protection
Para
/Global Prot
Para
/Prot]
ExBlo TripCmd
Fc
Activate (allow) the external blocking of the
trip command of the entire device.
inactive,
active
inactive [Protection
Para
/Global Prot
Para
/Prot]
515 MCDGV4 DOK-HB-MCDGV4-2E
