Module: Protection (Prot)
General Alarms and General Trips
Each protective element generates it´s own alarm and trip signals. All alarms and trip decision are passed on to the
master module
»Prot«.
If a protective element picks up, respectively has decided about a trip, two signals will be issued:
1. The module or the protection stage issues an alarm e.g. »I[1].ALARM« or »I[1].TRIP«.
2. The master module
»Prot«
collects/summarizes the signals and issues an alarm or a trip signal
»PROT.ALARM« »PROT.TRIP«.
Further examples: »PROT.ALARM L1« is a collective signal (OR-connected) for all alarms issued by any of the
protective elements concerning Phase L1.
»PROT.TRIP L1« is a collective signal (OR-connected) for all trips issued by any of the protective elements
concerning Phase L1.
»PROT.ALARM« is the collective alarm signal OR-ed from all protection elements.»PROT.TRIP« is the collective alarm
signal OR-ed from all protection elements.
The trip commands of a the protective elements have to be assigned within the Circuit Breaker Manager
CB
Manager
. Only those trip decisions that are assigned within the
CB Manager
are isssued to the Circuit Breaker.
Caution: Trip commands that are not assigned within the Circuit Breaker
Manager (CB Manager) are not issued to a circuit breaker.
The CB Manager issues the trip commands to a circuit breaker.
Assign within the Circuit Breaker Manager all trip commands that have to
switch a circuit breaker.
