Switchgear/Breaker – Manager
Single Line Diagram
The user can create and modify Single Lines (pages) by means of the
Page Editor
.
The Single Lines (Control Pages) have to be loaded into the protective device by means of
Smart view
.
For details on the creation, modification and upload of Single Lines (Control Pages) please refer to the manual
“page_editor_uk.pdf” or contact the technical support. The manual can be accessed via the
Page Editors
help
menu.
The single line diagram includes the graphically description of the switchgear and its designation (name) as well as
its features (short circuit proof or not ...). For displaying in the devices software, the switchgears' designations (e. g.
QA1, QA2, instead of SG[x]) will be taken from the single line diagram (configuration file).
The configuration file includes the single line diagram and the switchgear properties. Switchgear properties and
single line diagram are coupled via the configuration file.
The default settings of the switchgears depend on the used Single Line. The shown
default values correspond to a Single Line with two circuit breakers and to isolating
switches.
526 MCDGV4 DOK-HB-MCDGV4-2E
