Device Parameters
Direct Commands of the System Module
Parameter Description Setting range Default Menu path
Ack BO LED Scd
TCmd
Reset the binary output relays, LEDs, SCADA
and the Trip Command.
inactive,
active
inactive [Operation
/Acknowledge]
Ack LED All acknowledgeable LEDs will be
acknowledged.
inactive,
active
inactive [Operation
/Acknowledge]
Ack BO All acknowledgeable binary output relays
will be acknowledged.
inactive,
active
inactive [Operation
/Acknowledge]
Ack Scada SCADA will be acknowledged. inactive,
active
inactive [Operation
/Acknowledge]
Reboot Rebooting the device. no,
yes
no [Service
/General]
Setting Lock
Bypass
Short-period unlock of the Setting Lock inactive,
active
inactive [Field Para
/General
Settings]
CAUTION, rebooting the device manually will release the Supervision Contact.
Global Protection Parameters of the System
Parameter Description Setting range Default Menu path
PSet-Switch Switching Parameter Set PS1,
PS2,
PS3,
PS4,
PSS via Inp fct,
PSS via Scada
PS1 [Protection
Para
/PSet-Switch]
