Device Configuration Parameters of the Device
Parameter Description Options Default Menu path
Hardware
Variant 1
Optional Hardware Extension »A« 16 digital
inputs | 11 binary
output relays,
»B« 8 digital inputs
| 11 binary output
relays | 2 Analog
Inputs | 2 Analog
Outputs,
»C« 24 digital
inputs | 11 binary
output relays,
»D« 16 digital
inputs | 16 binary
output relays
16 digital
inputs | 11
binary output
relays
[MCDGV4]
Hardware
Variant 2
Optional Hardware Extension »0« Phase Current
5A/1A, Ground
Current 5A/1A,
»1« Phase Current
5A/1A, Sensitive
Ground Current
5A/1A
Phase Current
5A/1A, Ground
Current 5A/1A
[MCDGV4]
Housing Mounting form »A« Flush
mounting,
»B« 19 inch
mounting (semi-
flush),
»H« Customized
Version 1,
»K« Customized
Version 2
Flush
mounting
[MCDGV4]
