Parameters
Parameters
Parameter setting and planning can be done:
directly at the device or
by way of the
Smart view
software.
Parameter Definitions
Device Parameters
Device Parameters
are part of the Parameter Tree. By means of them you can (depending on the type of device):
• Set cutoff levels,
• Configure Digital Inputs,
• Configure Output Relays,
• Assign LEDs,
• Assign Acknowledgment Signals,
• Configure Statistics,
• Configure Protocol Parameters,
• Adapt HMI Settings,
• Configure Recorders (reports),
• Set Date and Time,
• Change Passwords,
• Check the version (build) of the device.
Field Parameters
Field Parameters
are part of the Parameter Tree. Field Parameters comprise the essential, basic settings of your
switchboard such as rated frequency, transformer ratios.
Protection Parameters
Protection Parameters
are part of the Parameter Tree. This tree comprises:
•
Global Protection Parameters are part of the Protection Parameters:
All settings and assignments that are
done within the Global Parameter Tree are valid independent of the Setting Groups. They have to be set
once only. In addition to that they comprise the CB Management.
•
The Parameter Setting Switch is part of the Protection Parameters:
You can either direct switch onto a
certain parameter setting group or you can determine the conditions for switching onto another parameter
setting group.
•
Setting Group Parameters are part of the Protection Parameters:
By means of the Parameter Setting
Group Parameters you can individually adapt your protective device to the current conditions or grid
conditions. They can be individually set in each Setting group.
441 MCDGV4 DOK-HB-MCDGV4-2E
