Installation and Connection
Slot X5: Multi Input – Output Card
Rear side of the device (Slots)
The type of card in this slot is dependent on the ordered device type. The different variants have a different scope of
functions.
Available assembly groups in this slot:
(DI8-OR4 X5): Assembly Group with 8 Digital Inputs and 4 Output Relays .
(AN I02-OR4 X5): Assembly Group with 2 Analog Inputs, 2 Analog Outputs and 4 Output Relays.
The available combinations can be gathered from the ordering code.
59 MCDGV4 DOK-HB-MCDGV4-2E
