Installation and Connection
Installation and Connection
Three-Side-View - 19”
Dependent on the connection method of the SCADA system used the needed
space (depth) differs. If, for instance, a D-Sub-Plug is used, it has to be added
to the depth dimension.
The three-side-view shown in this section is exclusively valid for
19” devices.
3-Side-View B2 Housing (19” Devices). (All dimensions in mm, except dimensions in brackets [inch].)
29 MCDGV4 DOK-HB-MCDGV4-2E
