Device Parameters
System Module Signals
Signal Description
Reboot Signal: Rebooting the device: 1=Normal Start-up; 2=Reboot by the
Operator; 3=Reboot by means of Super Reset; 4=outdated; 5=outdated;
6=Unknown Error Source; 7=Forced Reboot (initiated by the main
processor); 8=Exceeded Time Limit of the Protection Cycle; 9= Forced
Reboot (initiated by the digital signal processor); 10=Exceeded Time Limit
of the Measured Value Processing; 11=Sags of the Supply Voltage;
12=Illegal Memory Access.
Act Set Signal: Active Parameter Set
PS 1 Signal: Parameter Set 1
PS 2 Signal: Parameter Set 2
PS 3 Signal: Parameter Set 3
PS 4 Signal: Parameter Set 4
PSS manual Signal: Manual Switch over of a Parameter Set
PSS via Scada Signal: Parameter Set Switch via Scada. Write into this output byte the
integer of the parameter set that should become active (e.g. 4 => Switch
onto parameter set 4).
PSS via Inp fct Signal: Parameter Set Switch via input function
min 1 param changed Signal: At least one parameter has been changed
Setting Lock Bypass Signal: Short-period unlock of the Setting Lock
Param to be saved Number of parameters to be saved. 0 means that all parameter changes
are overtaken.
Ack LED Signal: LEDs acknowledgement
Ack BO Signal: Acknowledgement of the Binary Outputs
Ack Counter Signal: Reset of all Counters
Ack Scada Signal: Acknowledge Scada
Ack TripCmd Signal: Reset Trip Command
Ack LED-HMI Signal: LEDs acknowledgement :HMI
Ack BO-HMI Signal: Acknowledgement of the Binary Outputs :HMI
Ack Counter-HMI Signal: Reset of all Counters :HMI
Ack Scada-HMI Signal: Acknowledge Scada :HMI
Ack TripCmd-HMI Signal: Reset Trip Command :HMI
Ack LED-Sca Signal: LEDs acknowledgement :SCADA
Ack BO-Sca Signal: Acknowledgement of the Binary Outputs :SCADA
Ack Counter-Sca Signal: Reset of all Counters :SCADA
Ack Scada-Sca Signal: Acknowledge Scada :SCADA
Ack TripCmd-Sca Signal: Reset Trip Command :SCADA
Res OperationsCr Signal:: Res OperationsCr
Res AlarmCr Signal:: Res AlarmCr
Res TripCmdCr Signal:: Res TripCmdCr
Res TotalCr Signal:: Res TotalCr
