Field Parameters
Field Parameters
Field Para
Within the field parameters you can set all parameters, that are relevant for the primary side and the mains
operational method like frequency, primary and secondary values...
General Field Parameters
Parameter Description Setting range Default Menu path
Phase
Sequence
Phase Sequence direction ABC,
ACB
ABC [Field Para
/General
Settings]
f Nominal frequency 50Hz,
60Hz
50Hz [Field Para
/General
Settings]
