Woodward HighPROTEC - Protection Module Input States; Protection Module Signals (Output States)

Module: Protection (Prot)
Parameter Description Setting range Default Menu path
ExBlo TripCmd If external blocking of the tripping command
is activated (allowed), the tripping
command of the entire device will be
blocked if the state of the assigned signal
becomes true.
1..n,
Assignment List
-.- [Protection
Para
/Global Prot
Para
/Prot]
Protection Module Input States
Name Description Assignment via
ExBlo1-I Module input state: External blocking1 [Protection Para
/Global Prot Para
/Prot]
ExBlo2-I Module input state: External blocking2 [Protection Para
/Global Prot Para
/Prot]
ExBlo TripCmd-I Module input state: External Blocking of the Trip
Command
[Protection Para
/Global Prot Para
/Prot]
Protection Module Signals (Output States)
Signal Description
available Signal: Protection is available
active Signal: active
ExBlo Signal: External Blocking
Blo TripCmd Signal: Trip Command blocked
ExBlo TripCmd Signal: External Blocking of the Trip Command
Alarm L1 Signal: General-Alarm L1
Alarm L2 Signal: General-Alarm L2
Alarm L3 Signal: General-Alarm L3
Alarm G Signal: General-Alarm - Earth fault
Alarm Signal: General Alarm
Trip L1 Signal: General Trip L1
Trip L2 Signal: General Trip L2
Trip L3 Signal: General Trip L3
Trip G Signal: General Trip Ground fault
Trip Signal: General Trip
Res FaultNo a GridFaultNo Signal: Resetting of fault number and grid fault number.
I dir fwd Signal: Phase current failure forward direction
