Protective Elements
I - Overcurrent Protection [50, 51,51Q, 51V, 67]
Available stages:
I[1] ,I[2] ,I[3] ,I[4] ,I[5] ,I[6]
If you are using inrush blockings the tripping delay of the current protection
functions must be at least 30ms or more in order to prevent faulty trippings.
In order to ensure correct functioning of the directional detection after single-
phase short-circuits, the following reference voltage is used: For phase current
I1
it is the line-to-line voltage
U23
, for phase current
I2
the line-to-line voltage
U31
and for phase current
I3
the line-to-line voltage
U12
.
In case the fault happens to be near the measuring location and there is no
reference voltage for directional recognition available any more (neither
measured or from history (voltage memory)), then the module will - depending
on the parameter setting - either trip non-directional or it will be blocked.
All overcurrent protective elements are identically structured.
The setting parameter »CT Winding Side«) allows to select which CT the
protective element monitors
(CT Ntrl=Current transformers on the neutral side, or
CT Mains=Current Transformer Main Side).
It must be noted, however, that the direction determination is available only with
the setting »CT Winding Side« = CT Mains.
This module offers Adaptive Parameter Sets.
Parameters can be modified within parameter sets dynamically by means of
Adaptive Parameter Sets.
Please refer to chapter Parameter / Adaptive Parameter Sets.
