Communication Protocols
Communication Protocols
SCADA Interface
Scada
Device Planning Parameters of the Serial Scada Interface
Parameter Description Options Default Menu path
Protocol Select the SCADA protocol to be used. do not use,
Modbus RTU,
Modbus TCP,
Modbus TCP/RTU,
DNP3 RTU,
DNP3 TCP,
DNP3 UDP,
IEC60870-5-103,
IEC61850,
Profibus
do not use [Device planning]
Signals (Output States) of the SCADA Interface
Signal Description
SCADA connected At least one SCADA System is connected to the device.
SCADA not connected No SCADA System is connected to the device
TCP/IP Parameter
TcpIp
Global TCP/IP Parameters
Parameter Description Setting range Default Menu path
Keep Alive
Time
Keep Alive Time is the duration between two
keep alive transmissions in idle condition
1 - 7200s 720s [Device Para
/TCP/IP
/Advanced
Settings]
Keep Alive
Interval
Keep Alive Interval is the duration between
two successive keep alive retransmissions,
if the acknowledgement to the previous
keepalive transmission was not received.
1 - 60s 15s [Device Para
/TCP/IP
/Advanced
Settings]
317 MCDGV4 DOK-HB-MCDGV4-2E
