Measuring Values
Measuring Values
Read out Measured Values
In menu »Operation/Measured Values« both measured and calculated values can be viewed. The measured values
are ordered by »Standard values« and »special values« (depending on the type of device).
Measurement Display
Menu [Device Para\Measurem Display] offers options to change the display of measured values.
Scaling of Measured values
By means of the parameter »Scaling« the user can determine how measured values are to be displayed within the
HMI and
Smart view
:
Primary quantities
Secondary quantities
Per Unit quantities
Power Units (applies only for devices with power measurement)
By means of the parameter »
Power Units«
the User can determine how measured values are to be displayed within
the HMI and
Smart view
:
Power Auto Scaling
kW, kVAr or kVA
MW, MVAr or MVA
GW, GVAr or GVA
232 MCDGV4 DOK-HB-MCDGV4-2E
